Architecture (MMVC)

How modules, controllers, views, models, the registry and the dispatcher orbit each other.

Stable Reading time ~ 3 min Edit on GitHub

Nibiru is MMVC: Model — View — Controller — and a second M for Module. The first three are familiar; the second M is what gives Nibiru its flavour.

Cross-section illustration of the Nibiru runtime drawn as a lotus, with each petal labeled as a system component: Router, Controller, View, Model, Module, Registry. — The Nibiru runtime, drawn as a lotus.

The 30-second mental model

Request lifecycle: Browser to index.php to framework.php to Dispatcher, fanning out to Router, Modules, Autoloader, then to applicationController (navigationAction, custom action, pageAction), then to Smarty render. — Every request follows this path. The dispatcher fans out to Router / Modules / Autoloader, then invokes the controller's actions in order, then hands the assigned data to Smarty.

The five citizens

1. Controllers (`application/controller/`)

A controller is a class extending Nibiru\Adapter\Controller. The dispatcher invokes a fixed sequence on every request:

navigationAction() — populate menus / breadcrumb data.
<_action>Action() — only if ?_action=foo is set.
pageAction() — final render-time data assignment.

After all three return, Display::display() hands the assigned variables to Smarty.

2. Views (`application/view/templates/`)

Smarty .tpl files. The dispatcher resolves <controller>.tpl automatically; nested actions go under templates/<controller>/<action>.tpl. Every variable passed via View::assign(['x' => ...]) is available as {$x}.

3. Models (`application/model/`)

Models are auto-generated from your DB schema by Model::__construct(false) — one PHP class per table. They extend Nibiru\Adapter\<Driver>\Db and expose CRUD helpers. You can hand-edit a generated model and disable the regenerator with [GENERATOR] database = false.

4. Modules (`application/module/<name>/`)

A module bundles its own traits, plugins, interfaces and settings. The Registry auto-discovers each module’s settings/*.ini and exposes the parsed config via Registry::getInstance()->loadModuleConfigByName('users'). Modules can implement SplSubject for the observer pattern, letting other parts of the system attach observers and react to state changes.

5. Singletons that hold the cosmos together

Singleton	Job
`Config::getInstance()`	Reads `settings.<env>.ini` and merges in module configs.
`Router::getInstance()`	Parses the URL into controller/action/params; recognises SEO URL forms.
`Registry::getInstance()`	Module discovery + config caching.
`Dispatcher::getInstance()`	The conductor. `dispatch::run()` is your application’s heartbeat.
`View::getInstance()`	Wraps Smarty. `View::assign()` is the global template-variable inbox.

Why MMVC, not MVC?

Plain MVC works until your controllers start sharing logic — auth checks, form factories, third-party API clients. The usual answers are services + DI container, but that’s a lot of ceremony for a rapid-prototyping framework.

Nibiru’s answer: modules. A module owns a domain (users, cms, analytics, tpms-quotes), exposing its services via plugins controllers can instantiate directly:

// In a controller
$user = new \Nibiru\Module\Users\Plugin\User();
if (!$user->isAuthorized()) {
    View::forwardTo('/login');
}

The module owns its config, its DB tables, its templates, its forms — and is removable as a unit.

The observer pattern, in practice

Some modules implement SplSubject so other code can react to events without coupling. From the showcase, the analytics module on prod.maschinen-stockert.de does exactly this: any controller can attach() a tracker (Matomo plugin) and the analytics module notify()s on every page-view, without the controller knowing what trackers exist.

class Analytics implements \SplSubject {
    private \SplObjectStorage $observers;
    public function __construct() { $this->observers = new \SplObjectStorage(); }
    public function attach(\SplObserver $o): void { $this->observers->attach($o); }
    public function detach(\SplObserver $o): void { $this->observers->detach($o); }
    public function notify(): void {
        foreach ($this->observers as $o) { $o->update($this); }
    }
}

What’s deliberately not in the framework

No DI container. Singletons + plugins do the job.
No ORM. Models are generated from the schema; queries use the Db adapter or raw SQL via the active driver.
No template inheritance through Twig/Blade tricks. Smarty {include} is the unit of composition.
No event bus. SplSubject/SplObserver are first-class.
No first-class background jobs. The CLI is your scheduler — drive it from cron or systemd timers.

Less to learn, more to ship.

Where to go next

Bootstrap & Dispatcher — the lifecycle in code.
Routing — URL → controller mapping rules.
Modules — build your first one.
